Description
Ford Maverick Lobo™ 2.5L Fhev Awd 2.5L Hybrid
Specifications
Manufacturer
Ford
Model
Maverick Lobo™ 2.5L Fhev Awd 2.5L Hybrid
Year
2026
Category
Pickup Trucks
Subcategory
Super Duty Pickups
Fuel Delivery
PFI
Battery Cooling System
Liquid
Ramp Breakover Angle - Curb
15.9/17.0
Configuration
Aluminum block and head, Atkinson cycle I-4
Manufacturing Location
Chihuahua Mexico
Intake Manifold
Composite
Exhaust Manifold
Welded Tubular Steel
Valvetrain
DOHC, IVCT
Pistons
Aluminum
Connecting Rods
Powder Forged
Compression Ratio
13.0:1
Crankshaft
Forged Steel
Oil Capacity
5.7 Quarts
Coolant Capacity
9.62 Quarts (Gas Engine) / 4.92 Quarts (Electric)
Electric Motor Type
Permanent Magnet Electric Traction (Ford In House E_Motor)
Electric Motor Output
94 kW/173 lb-ft battery peak
Battery Location
Passenger Side Under Cabin
Transmission
Power-Split Electronic CVT (2.5L Hybrid)/7-Speed Automatic (Maverick Lobo™)
Gear Ratios
1st: 4.69
Final Gear Ratio
3.37:1
Brakes
4-wheel disc brakes with ABS and regenerative braking system
2.5L Hybrid
2,000 lbs/4,000 lbs
2.5L FHEV AWD
1,400 lbs
Vehicle Length
199.8/200.9
Vehicle Height - Maximum
68.3/67.7
Vehicle Width*
72.6/72.6
Body Width - Maximum
72.4/72.4
Vehicle Width - Including Outside Mirrors
83.5/83.5
Vehicle Width - with Mirrors Folded
77.9/77.9
Lift in Height
29.4/28.2
Pickup Body Height
20.3/20.3
Pickup Body Length at Floor
54.4/54.4
Cargo Width - Wheel House
42.6/42.6
Exposed Cargo Width
53.3/53.3
Open trucks and MPV Cargo Volume
33.3/33.3
Bore and Stroke
3.50 x 3.94 in
Displacement
152.6 cu in
Wheel Base
121.1/121.1
Vehicle Track Front Curb
63.7/63.7
Vehicle Track Rear Curb
62.7/63.1
Front Overhang
34.2/34.7
Rear Overhang
44.5/45.0
Approach Angle
20.4/19.0
Departure Angle
21.0/19.3
Minimum Running Ground Clearance
8.1/7.4
Front of Bumper to Back of Cab
137.7/138.2
Effective Head Room - Front
40.2/40.2
Effective Head Room - Second
39.6/39.6
Maximum Leg Room - Accelator
42.8/42.8
Effective Leg Room - Second
35.9/36.9
Hip Room - Front
55.4/55.4
Hip Room - Second
54.1/54.1
Shoulder Room - Front
57.3/57.3
Shoulder Room Beltline - Second
55.6/55.6
