Description
Ford Maverick® Xlt 2.0L Ice Awd 2.5L Hybrid
Specifications
Manufacturer
Ford
Model
Maverick® XLT 2.0L Ice Awd 2.5L Hybrid
Year
2026
Category
Pickup Trucks
Subcategory
Super Duty Pickups
Engine - Configuration
Aluminum block and head, Atkinson cycle I-4/Aluminum block and head, I-4
Engine - Manufacturing Location
Chihuahua Mexico/Dearborn, Michigan
Engine - Intake Manifold
Composite/Composite
Engine - Exhaust Manifold
Welded Tubular Steel/Integrated
Engine - Valvetrain
DOHC, IVCT/DOHC, Ti-VCT
Engine - Pistons
Aluminum/Aluminum
Engine - Connecting Rods
Powder Forged/Powder Forged
Engine - Bore and Stroke
3.50 x 3.94 in/3.31 x 3.54 in
Engine - Displacement
152.6 cu in/121.7 cu in
Engine - Compression Ratio
13.0:1/10.8:1
Engine - Crankshaft
Forged Steel/Forged Steel
Engine - Horsepower*
/250 hp @ 5,500 rpm
Engine - Torque*
/280 lb-ft @ 3,000 rpm
Engine - Fuel Delivery
PFI/GTDI and Port Injection
Engine - Oil Capacity
5.7 Quarts/6.1 Quarts
Engine - Coolant Capacity
9.62 Quarts (Gas Engine) / 4.92 Quarts (Electric)/9.2 Quarts
Engine - Electric Motor Type
Permanent Magnet Electric Traction (Ford In House E_Motor)
Engine - Electric Motor Output
94 kW/173 lb-ft battery peak
Engine - Battery Cooling System
Liquid
Engine - Battery Location
Passenger Side Under Cabin
Fuel Economy**
40 city / 34 highway / 37 combined/22 city / 30 highway / 25 combined
Ramp Breakover Angle - Curb
15.9/18.3
Transmission
Power-Split Electronic CVT (2.5L Hybrid)/8-Speed Automatic (2.0L EcoBoost®)
Gear Ratios - 1st
/4.69
Gear Ratios - 2nd
/3.31
Gear Ratios - 3rd
/3.01
Gear Ratios - 4th
/1.92
Gear Ratios - 5th
/1.45
Gear Ratios - 6th
/1
Gear Ratios - 7th
/0.75
Gear Ratios - 8th
/0.62
Final Gear Ratio
3.37:1/3.63 Standard/3.81 with available 4K Tow Pkg
Reverse
/-2,96
Steering
Electric power-assisted steering (EPAS)
Turning Circle (Curb to Curb)
40 Feet
Towing - 2.5L Hybrid
2,000 lbs/4,000 lbs
Towing - 2.0L EcoBoost®
2,000 lbs/4,000 lbs
Payload - 2.0L AWD
1,500 lbs
Payload - 2.5L FHEV AWD
1,400 lbs
Vehicle Length
199.8/199.8
Vehicle Height - Maximum
68.3/68.5
Vehicle Width*
72.6/72.6
Body Width - Maximum
72.4/72.4
Vehicle Width - Including Outside Mirrors
83.5/83.5
Vehicle Width - with Mirrors Folded
77.9/77.9
Lift in Height
29.4/29.4
Pickup Body Height
20.3/20.3
Pickup Body Length at Floor
54.4/54.4
Cargo Width - Wheel House
42.6/42.6
Exposed Cargo Width
53.3/53.3
Open trucks and MPV Cargo Volume
33.3/33.3
Wheel Base
121.1/121.1
Vehicle Track Front Curb
63.7/63.5
Vehicle Track Rear Curb
62.7/62.6
Front Overhang
34.2/34.2
Rear Overhang
44.5/44.5
Approach Angle
20.4/21.1
Departure Angle
21.0/21.1
Minimum Running Ground Clearance
8.1/8.3
Front of Bumper to Back of Cab
137.7/137.7
Effective Head Room - Front
40.2/40.2
Effective Head Room - Second
39.6/39.6
Maximum Leg Room - Accelator
42.8/42.8
Effective Leg Room - Second
35.9/36.9
Hip Room - Front
55.4/55.4
Hip Room - Second
54.1/54.1
Shoulder Room - Front
57.3/57.3
Shoulder Room Beltline - Second
55.6/55.6
