Description
Ford Maverick® Xl 2.0L Ice Awd 2.5L Hybrid
Specifications
Manufacturer
Ford
Model
Maverick® XL 2.0L Ice Awd 2.5L Hybrid
Year
2026
Category
Pickup Trucks
Subcategory
Super Duty Pickups
Horsepower*
/250 hp @ 5,500 rpm
Torque*
/280 lb-ft @ 3,000 rpm
Fuel Delivery
PFI/GTDI and Port Injection
Battery Cooling System
Liquid
Ramp Breakover Angle - Curb
16.7 deg/15.9 deg/18.3 deg
Configuration
Aluminum block and head, Atkinson cycle I-4/Aluminum block and head, I-4
Manufacturing Location
Chihuahua Mexico/Dearborn, Michigan
Intake Manifold
Composite/Composite
Exhaust Manifold
Welded Tubular Steel/Integrated
Valvetrain
DOHC, IVCT/DOHC, Ti-VCT
Pistons
Aluminum/Aluminum
Connecting Rods
Powder Forged/Powder Forged
Compression Ratio
13.0:1/10.8:1
Crankshaft
Forged Steel/Forged Steel
Oil Capacity
5.7 Quarts/6.1 Quarts
Coolant Capacity
9.62 Quarts (Gas Engine) / 4.92 Quarts (Electric)/9.2 Quarts
Electric Motor Type
Permanent Magnet Electric Traction (Ford In House E_Motor)
Electric Motor Output
94 kW/173 lb-ft battery peak
Battery Location
Passenger Side Under Cabin
Transmission
Power-Split Electronic CVT (2.5L Hybrid)/8-Speed Automatic (2.0L EcoBoost®)
Final Gear Ratio
3.37:1/3.63 Standard/3.81 with available 4K Tow Pkg
Reverse
/-2,96
Steering
Electric power-assisted steering (EPAS)
Turning Circle (Curb to Curb)
40 Feet
Towing - 2.5L Hybrid - Base (FWD/AWD/4WD)
2,000 lbs
Towing - 2.5L Hybrid - 4K Tow Package (AWD)
4,000 lbs
Towing - 2.0L EcoBoost® - Base (FWD/AWD/4WD)
2,000 lbs
Towing - 2.0L EcoBoost® - 4K Tow Package (AWD)
4,000 lbs
Payload - 2.0L AWD
1,500 lbs
Payload - 2.5L FHEV AWD
1,400 lbs
Vehicle Length
199.8 inch/199.8 inch/199.8 inch
Vehicle Height - Maximum
68.8 inch/68.3 inch/68.5 inch
Vehicle Width*
72.6 inch/72.6 inch/72.6 inch
Body Width - Maximum
72.4 inch/72.4 inch/72.4 inch
Vehicle Width - Including Outside Mirrors
83.5 inch/83.5 inch/83.5 inch
Vehicle Width - with Mirrors Folded
77.9 inch/77.9 inch/77.9 inch
Lift in Height
30.4 inch/29.4 inch/29.4 inch
Pickup Body Height
20.3 inch/20.3 inch/20.3 inch
Pickup Body Length at Floor
54.4 inch/54.4 inch/54.4 inch
Cargo Width - Wheel House
42.6 inch/42.6 inch/42.6 inch
Exposed Cargo Width
53.3 inch/53.3 inch/53.3 inch
Open trucks and MPV Cargo Volume
33.3 cubic feet/33.3 cubic feet/33.3 cubic feet
Bore and Stroke
3.50 x 3.94 in/3.31 x 3.54 in
Displacement
152.6 cu in/121.7 cu in
Wheel Base
121.1 inch/121.1 inch/121.1 inch
Vehicle Track Front Curb
63.6 inch/63.7 inch/63.5 inch
Vehicle Track Rear Curb
63.0 inch/62.7 inch/62.6 inch
Front Overhang
34.2 inch/34.2 inch/34.2 inch
Rear Overhang
44.5 inch/44.5 inch/44.5 inch
Approach Angle
20.3 deg/20.4 deg/21.1 deg
Departure Angle
22.2 deg/21.0 deg/21.1 deg
Minimum Running Ground Clearance
8.1 inch/8.1 inch/8.3 inch
Front of Bumper to Back of Cab
137.7 inch/137.7 inch/137.7 inch
Effective Head Room - Front
40.2 inch/40.2 inch/40.2 inch
Effective Head Room - Second
39.6 inch/39.6 inch/39.6 inch
Maximum Leg Room - Accelator
42.8 inch/42.8 inch/42.8 inch
Effective Leg Room - Second
35.9 inch/35.9 inch/36.9 inch
Hip Room - Front
55.4 inch/55.4 inch/55.4 inch
Hip Room - Second
54.1 inch/54.1 inch/54.1 inch
Shoulder Room - Front
57.3 inch/57.3 inch/57.3 inch
Shoulder Room Beltline - Second
55.6 inch/55.6 inch/55.6 inch
