2026 Ford F-150® Raptor® 5.0L Ti-Vct V8 Supercrew® 6.5-Ft. Styleside 4X2
Pickup TrucksSuper-Duty
Description
Ford F-150® Raptor® 5.0L Ti-Vct V8 Supercrew® 6.5-Ft. Styleside 4X2
Specifications
Manufacturer
Ford
Model
F-150® Raptor® 5.0L Ti-Vct V8 Supercrew® 6.5-Ft. Styleside 4X2
Year
2026
Category
Pickup Trucks
Subcategory
Super-Duty
Wheelbase
157.2 in
Overall length
243.8 in
Cab height
77.5 in
Width - Excluding mirrors
79.9 in
Width - Including standard mirrors
95.7 in
Width - Standard Mirrors folded
83.6 in
Track width - Front
67.9 in
Track width - Rear
68.3 in
Overhang - Front
37.4 in
Overhang - Rear
49.2 in
Ground clearance
9.7 in
Front bumper to back of cab
155.6 in
Open Tailgate to Ground (Lift-In Height)
34.1 in
Inside Length (at floor)
78.9 in
Width between wheelhouses
50.6 in
Inside Height
21.4 in
Head room - Front
40.8 in
Head room - Rear
40.4 in
Shoulder room - Front
66.6 in
Shoulder room - Rear
65.8 in
Hip room - Front
62.5 in
Hip room - Rear
62.6 in
Max Leg room - Front
43.9 in
Leg room - Rear
43.6 in
Drive system
4x2
Angle of approach
24.8 degrees
Angle of departure
27.7 degrees
Ramp breakover angle
18.8 degrees
Cargo box volume
62.3 cu ft
Cab style
SuperCrew®
Maximum Seating Capacity
6
Minimum Seating Capacity
5
Fuel capacity - Extended Range
36 gallons*
Fuel capacity - PowerBoost® Hybrid
30.6 gallons
Pickup box style
6.5-ft. Styleside
Engine type
5.0L Ti-VCT V8
Engine Control System
Electronic
Horsepower (hp@rpm)
400 @ 6,000
Torque (lb-ft @rpm)
410 @ 4,250
Compression ratio
12:1
Bore (in)
3.66
Stroke (in)
3.65
Displacement (cu in)
307
Main bearings
5
Valve operation
Roller Finger Follower
Fuel delivery
Port Fuel Injection and Direct Injection
Recommended fuel
Regular Unleaded or E85
Oil Capacity (qt)
7.75
Coolant Capacity (L)
12.5
Transmission type
Electronic 10-Speed Automatic
Engine block material
Aluminum
Cylinder head material
Aluminum
