Description
Ford 2025 Transit® Cargo Van 3.5L PFDI V6 Long-EL High
Specifications
Manufacturer
Ford
Model
2025 Transit® Cargo Van 3.5L PFDI V6 Long-EL High
Year
2025
Category
Van Trucks
Subcategory
Van Trucks
Engine type
3.5L PFDI V6
Horsepower (SAE net @ RPM)
275 @ 6,250
Torque (lb-ft @ RPM)
260 @ 4,000
Fuel delivery
Port Fuel Direct Injection (PFDI) dual system
Engine block material
Aluminum
Cylinder head material
Aluminum
Engine
3.5L PFDI V6
Displacement (cu In / ml)
213/3,497
Bore x stroke (in)
3.64 x 3.41
Compression ratio
11.8.1
Transmission type
10-speed automatic Selectshift® with overdrive
Roof (Low, Medium, High)
High
Passenger Capacity
2
Rows of Seating
1
Seating
2
Valvetrain
DOHC, 4 valve per cylinder
Front suspension
Independent MacPherson-strut
Rear suspension
Leaf springs
Shock absorbers
Heavy-duty gas
Brakes
4-wheel anti-lock disc brakes
Steering
Electric Power Steering (EPS)
Transit Level
T-350
Roof
High
RWD/AWD
RWD
GVWR (lbs)
9,500 lbs
Max Payload (lbs)
3,950 lbs
Length (Regular, Long, Long-EL)
Long-EL
Cargo Width Between Wheelhouse (SRW/DRW)
54.8 / 45.4
Length
Long-EL
Wheelbase
148 in
Overall Length
263.9 in
Height
110.4 in
Width - Excluding Mirrors (SRW/DRW)
81.3/83.7 in
Width - Including Mirrors
97.4 in
Width - Mirrors Folded
83.2/83.7 in
Front Track (SRW/DRW)
68.2/68.5 in
Rear Track (SRW/DRW)
68.6/65.7 in
Front Overhang
40.3 in
Rear Overhang
76 in
Load Height (Curb)
28 in
Side Cargo Door Opening Height
63 in
Side Cargo Door Opening Width - Hinged
51.2 in
Side Cargo Door Opening Width - Sliding
51.2 in
Rear Cargo Door Opening Height
74.3 in
Rear Cargo Door Opening Width
61.7 in
Head Room - First Row
56.6 in
Maximum Leg Room - First Row
41.3 in
Leg Room - First Row
39.7 in
Hip Room - First Row
60.7 in
Shoulder Room - First Row
67.9 in
Cargo Length Front (at Floor)
172.2 in
Cargo Length Front (at Belt)
162 in
Cargo Height Maximum
81.5 in
Cargo Volume Behind First Row
487,3 cu ft
Maximum Cargo Volume
536,4 cu ft
