Description
Ford 2025 Transit® Cargo Van 3.5L PFDI V6 Long Medium
Specifications
Manufacturer
Ford
Model
2025 Transit® Cargo Van 3.5L PFDI V6 Long Medium
Year
2025
Category
Van Trucks
Subcategory
Van Trucks
Engine type
3.5L PFDI V6
Horsepower (SAE net @ RPM)
275 @ 6,250
Torque (lb-ft @ RPM)
260 @ 4,000
Fuel delivery
Port Fuel Direct Injection (PFDI) dual system
Engine block material
Aluminum
Cylinder head material
Aluminum
Engine
3.5L PFDI V6
Displacement (cu In / ml)
213/3,497
Bore x stroke (in)
3.64 x 3.41
Compression ratio
11.8.1
Transmission type
10-speed automatic Selectshift® with overdrive
Roof (Low, Medium, High)
Medium
Passenger Capacity
2
Rows of Seating
1
Seating
2
Valvetrain
DOHC, 4 valve per cylinder
Front suspension
Independent MacPherson-strut
Rear suspension
Leaf springs
Shock absorbers
Heavy-duty gas
Brakes
4-wheel anti-lock disc brakes
Steering
Electric Power Steering (EPS)
Transit Level
T-250
Roof
Medium
RWD/AWD
RWD
GVWR (lbs)
9,070 lbs
Max Payload (lbs)
3,818 lbs
Length (Regular, Long, Long-EL)
Long
Length
Long
Wheelbase
148 in
Overall Length
235.5 in
Height
101.3 in
Width - Excluding Mirrors (SRW/DRW)
81.3 in
Width - Including Mirrors
97.4 in
Width - Mirrors Folded
83.2 in
Front Track (SRW/DRW)
68.2 in
Rear Track (SRW/DRW)
68.6 in
Front Overhang
40.3 in
Rear Overhang
47.6 in
Load Height (Curb)
28.7 in
Side Cargo Door Opening Height
63 in
Side Cargo Door Opening Width - Hinged
51.2 in
Side Cargo Door Opening Width - Sliding
51.2 in
Rear Cargo Door Opening Height
64.9 in
Rear Cargo Door Opening Width
61.7 in
Head Room - First Row
52 in
Maximum Leg Room - First Row
41.3 in
Leg Room - First Row
39.7 in
Hip Room - First Row
60.7 in
Shoulder Room - First Row
67.9 in
Cargo Length Front (at Floor)
143.7 in
Cargo Length Front (at Belt)
133.6 in
Cargo Width Between Wheelhouse (SRW/DRW)
54.8 in
Cargo Height Maximum
72 in
Cargo Volume Behind First Row
357,1 cu ft
Maximum Cargo Volume
400,5 cu ft
