2025 Ford F-150 Raptor High-Output Supercharged 5.2L V8 Regular Cab 8.0-ft. Styleside 4x2
Pickup TrucksOff Roading
Description
Ford F-150 Raptor High-Output Supercharged 5.2L V8 Regular Cab 8.0-ft. Styleside 4x2
Specifications
Manufacturer
Ford
Model
F-150 Raptor High-Output Supercharged 5.2L V8 Regular Cab 8.0-ft. Styleside 4x2
Year
2025
Category
Pickup Trucks
Subcategory
Off Roading
Base Curb Weight - 3.5L PowerBoost® Full Hybrid V6
5,585 lbs
Engine Control System
Electronic
Horsepower (hp@rpm)
720 @ 6,650
Torque (lb-ft @rpm)
640 @ 4,250
Fuel delivery
Port Fuel Injection and Direct Injection
Recommended fuel
Premium Unleaded
Engine block material
Aluminum
Cylinder head material
Aluminum
Maximum Seating Capacity
6
Minimum Seating Capacity
5
Fuel capacity - Standard Range
23 gallons
Fuel capacity - Extended Range
36 gallons*
Cab style
SuperCrew®
Pickup box style
5.5-ft Styleside
Drive system
4x4
Angle of approach
20.8 degrees
Angle of departure
23.5 degrees
Ramp breakover angle
17.9 degrees
Base Curb Weight - 2.7L EcoBoost V6
4,941 lbs
Base Curb Weight - 5.0L Ti-VCT V8
5,020 lbs/5,267 lbs*
Base Curb Weight - 3.5L EcoBoost V6
5,096 lbs / 5,260 lbs*
Base Curb Weight - High-Output 3.5L EcoBoost V6 (F-150 Raptor® / F-150 Raptor® 37 Performance Pkg)
5,710 lbs / 5,867 lbs
Base Curb Weight - F-150 Raptor® R, 5.2L V8
5,950 lbs
Compression ratio
9.5:1
Main bearings
5
Valve operation
Roller Finger Follower
Oil Capacity (qt)
11.5 qt
Coolant Capacity (L)
12.0 (Engine) 3.1 Supercharger L
Transmission type
Electronic 10-Speed Automatic
Front suspension
Independent double-wishbone with coil-over shock and cast aluminum lower control arm
Rear suspension
5-link coil with Panhard rod
Brakes
Power 4-wheel anti-lock vented disc
Steering
Electric Power-Assisted
Displacement (cu in)
315 cu in
Inside Length (at floor)
97.6 in
Width between wheelhouses
50.6 in
Inside Height
21.4 in
Cargo box volume
77.4 cu ft
Wheelbase
141.5 in
Overall length
228.1 in
Cab height
75.0 in
Width - Excluding mirrors
79.9 in
Width - Including standard mirrors
95.7 in
Width - Standard Mirrors folded
83.6 in
Track width - Front
67.9 in
Track width - Rear
68.3 in
Overhang - Front
37.4 in
Overhang - Rear
49.2 in
Ground clearance
8.2 in
Front bumper to back of cab
121.2 in
Open Tailgage to Ground (Lift-In Height)
33.5 in
Head room - Front
40.8 in
Shoulder room - Front
66.7 in
Hip room - Front
62.5 in
Max Leg room - Front
43.9 in
Bore (in)
3.7 in
Stroke (in)
3.7 in
