2025 Ford F-150 STX High-Output Supercharged 5.2L V8 Regular Cab 6.5-ft. Styleside 4x4
Pickup TrucksOff Roading
Description
Ford F-150 STX High-Output Supercharged 5.2L V8 Regular Cab 6.5-ft. Styleside 4x4
Specifications
Manufacturer
Ford
Model
F-150 STX High-Output Supercharged 5.2L V8 Regular Cab 6.5-ft. Styleside 4x4
Year
2025
Category
Pickup Trucks
Subcategory
Off Roading
Engine type
High-Output Supercharged 5.2L V8
Engine Control System
Electronic
Horsepower (hp@rpm)
720 @ 6,650
Torque (lb-ft @rpm)
640 @ 4,250
Fuel delivery
Port Fuel Injection and Direct Injection
Recommended fuel
Premium Unleaded
Engine block material
Aluminum
Cylinder head material
Aluminum
Maximum Seating Capacity
6
Minimum Seating Capacity
5
Fuel capacity - Standard Range
23 gallons
Fuel capacity - Extended Range
36 gallons*
Angle of approach
23.7 degrees
Angle of departure
26.0 degrees
Ramp breakover angle
23.3 degrees
Cab style
Regular Cab
Pickup box style
6.5-ft Styleside
Drive system
4x4
Base Curb Weight - 5.0L Ti-VCT V8
4,655 lbs
Compression ratio
9.5:1
Bore (in)
3.7
Stroke (in)
3.7
Main bearings
5
Valve operation
Roller Finger Follower
Oil Capacity (qt)
11.5
Coolant Capacity (L)
12.0 (Engine) 3.1 Supercharger
Transmission type
Electronic 10-Speed Automatic
Front suspension
Independent double-wishbone with coil-over shock and stamped lower control arm
Rear suspension
Leaf spring/solid axle
Front and rear shocks
Heavy-duty gas-pressurized
Brakes
Power 4-wheel anti-lock vented disc
Steering
Electric Power-Assisted
Displacement (cu in)
315
Inside Length (at floor)
78.9 in
Width between wheelhouses
50.6 in
Inside Height
21.4 in
Cargo box volume
62.3 cu ft
Wheelbase
122.8 in
Overall length
209.4 in
Cab height
76.9 in
Width - Excluding mirrors
79.9 in
Width - Including standard mirrors
95.7 in
Width - Standard Mirrors folded
83.6 in
Track width - Front
67.9 in
Track width - Rear
68.3 in
Overhang - Front
37.4 in
Overhang - Rear
49.2 in
Ground clearance
9.8 in
Front bumper to back of cab
121.2 in
Open Tailgate to Ground (Lift-In Height)
35.6 in
Head room - Front
40.8 in
Shoulder room - Front
66.7 in
Hip room - Front
62.5 in
Max Leg room - Front
43.9 in
