Description
Ford 2023 E-TRANSIT CARGO VAN
Specifications
Manufacturer
Ford
Model
2023 E-TRANSIT CARGO VAN
Year
2025
Category
Van Trucks
Subcategory
Cargo Van
Wheelbase
178
Overall Length
263.4
Overall Cab Height (Curb)
86.5
Overall Width
83.1
Front Track
68.5
Rear Track
68.6
Cab Length
95.7
Cab Rear to Rear Axle
122.6
Top of Frame to Top of Cab
61.2
Rear Axle to End of Frame - or Rear Overhang
45.1
Load Height (Loaded)
25
Front Overhang
40.3
Passenger Capacity
2
Head Room - First Row
40.8
Maximum Leg Room - First Row
39.7
Hip Room - First Row
61.1
Shoulder Room - First Row
69.9
Wheelbase One 130"
130" (T-350 SRW,LR)
Cargo Van
130" (T-350 SRW,MR)
Wheelbase Two 148"
148" (T-350 SRW,LR)
Cargo Van One
148" (T-350 SRW,MR)
Wheelbase Three 178"
C/A 178" (T-350 SRW LR)
Cutaway / Chassis Cab
C/C 178" (T-350 SRW LR)
Drive Type
RWD
Available Engine
Electric Motor
Horsepower
198kW / 266 HP
Torque
198kW / 266 HP
Transmission
Single-Speed
Maximum GVWR (Cargo)
9,500 lbs
Maximum GVWR (Cutaway)
9,500 lbs (T-350 SRW)
Maximum GVWR (Chassis Cab)
9,500 lbs (T-350 SRW)
Pro Power On Board
120V/2.4kW
Engine type
Electric Motor
Torque (lb-ft)
317
Battery
68kWh Useable Energy High-Voltage Lithium-Ion Battery pack
Transmission type
Single-Speed Transmission
Front suspension
Independent MacPherson-strut and Stabilizer Bar
Rear suspension
Rear Independent Suspension with coil springs, semi-trailing arm STA and stabilizer bar
Shock absorbers
Gas-pressurized
Brakes (Front)
Power anti-lock vented disc
Brakes (Rear)
Power anti-lock solid disc
Steering
Electric Power Steering (EPAS)
Maximum Payload
3,880 lbs Cargo T-350 SRW LR, 130" W/B
Roof Options
Low, Medium, High
Length Options
Regular, Long, Long-EL
