Description
Ford - 2024 Ranger® LARIAT 2.7L EcoBoost® Auto Start-Stop Technology
Specifications
Manufacturer
Ford
Model
2024 Ranger® LARIAT 2.7L EcoBoost® Engine
Year
2025
Category
Pickup Trucks
Subcategory
Super-Duty
Wheelbase
128.7 in
Overall length
210.6 in
Cab height
74.4 in
Width - Excluding mirrors
79.8 in
Width - Including mirrors
86.7 in
Width - Mirrors folded
79.0 in
Track width - Front
63.8 in
Track width - Rear
63.8 in
Overhang - Front
34.1 in
Overhang - Rear
47.8 in
Ground clearance
9.3 in
Front bumper to back of cab
143.2 in
Cargo box style
5 ft Styleside (4x4)
Inside Length (at floor)
59.6 in
Width between wheelhouses
48.2 in
Inside Height
20.8 in
Head room - Front
41.0 in
Head room - Rear
38.3 in
Shoulder room - Front
57.1 in
Shoulder room - Rear
56.7 in
Hip room - Front
55.9 in
Hip room - Rear
54.1 in
Max Leg room - Front
43.7 in
Leg room - Rear
34.6 in
Bore (in)
3.267 in
Stroke (in)
3.267 in
Drive Type
4x4
Max Seating Capacity
5
Min Vehicle Base Curb Weight
4,415 lbs
Angle of approach
30.2 degrees
Angle of departure
25.8 degrees
Ramp breakover angle
23.0 degrees
Cargo box volume
43.5 cu ft
Fuel Capacity
18 gal
Engine Control System
PCM
Horsepower (SAE net @ rpm)
315
Compression ratio
10.0:1
Displacement (cu in)
165 cu in
Fuel delivery
Port fuel and direct injection
Recommended Fuel
87 Octane
Front and rear shocks
Gas-Pressurized
Brakes
Four-wheel power disc brakes with four-sensor, four-channel antilock braking system and AdvanceTrac electronic stability control
Steering
Electric power-assisted, rack-and-pinion
Axle Ratio
3.73
GCWR
12,588 lbs
Maximum Conventional Towing Capabilities*
7,500 lbs
GVWR
6,170 lbs
Maximum Payload Capabilities
1,542 lbs
Torque (lb-ft @ rpm)
400 lb-ft
Transmission type
Electronic 10-speed automatic
