2025 Ford 2024 Super Duty® F-350® LARIAT 6.7 HO Power Stroke® V8 Turbo Diesel
Pickup TrucksSuper-Duty
Description
2024 Super Duty® F-350® LARIAT 6.7 HO Power Stroke® V8 Turbo Diesel
Specifications
Manufacturer
Ford
Model
2024 Super Duty® F-350® LARIAT 6.7 HO Power Stroke® V8 Turbo Diesel
Year
2025
Category
Pickup Trucks
Subcategory
Super-Duty
Regular Cab Front (in) Head room
40.8
Regular Cab Front (in) Shoulder room
66.7
Regular Cab Front (in) Hip room
62.5
Regular Cab Front (in) Max leg room
43.9
Super Cab Front (in) Head room
40.8
Super Cab Front (in) Shoulder room
66.7
Super Cab Front (in) Hip room
62.5
Super Cab Front (in) Max leg room
43.9
Crew Cab Front (in) Head room
40.8
Crew Cab Front (in) Shoulder room
66.7
Crew Cab Front (in) Hip room
62.5
Crew Cab Front (in) Max leg room
43.9
Super Cab Rear (in) Head room
40.3
Super Cab Rear (in) Shoulder room
65.8
Super Cab Rear (in) Hip room
64.7
Super Cab Rear (in) Max leg room
33.5
Crew Cab Rear (in) Head room
40.4
Crew Cab Rear (in) Shoulder room
65.9
Crew Cab Rear (in) Hip room
64.7
Crew Cab Rear (in) Max leg room
43.6
Front (rotor diameter)
14.29" (363 mm)
Rear (rotor diameter)
14.29" (363 mm)
WHEELS Size
17," 18" or 20"
WHEELS Size One
17" DRW
Bolt-circle diameter
7.87" (200 mm) DRW
Engine Name
6.7L HO Power Stroke® V8 Turbo Diesel
Configuration
90-degree diesel V8, single turbocharger, in-block cams and overhead valves
Fuel injection/delivery
High-Pressure Common-Rail
Engine control system
Electronic
Induction system
Variable Geometry Turbocharger; with charge air cooler
Battery
Dual 12V-volt 750CCA 78-AH
Standard Alternator
250-amp
Cooling system
Pressurized series flow
Oil life monitor
Intelligent Oil Life Monitor®
Cylinders
8
Cylinder head
Aluminum
Block material
Compacted graphite iron
Valve operation
Push rod/rocker arms
Camshaft drive
Gear
Bore
3.90"
Stroke
4.25"
Compression ratio
15.2:1
Horsepower/rpm
500 @ 2,600
Torque lb-ft/rpm
1,200 @ 1,600
Recommended fuel
Ultra-low sulfur diesel/B20
Regular Cab Passenger - total
64.7
Super Cab Passenger - total
116.3
Crew Cab Passenger - total
131.9
Regular Cab Cargo - behind first row
10.9
Super Cab Cargo - behind first row
30.3
Crew Cab Cargo - behind first row
53.4
Seating capacity Regular Cab
3
Seating capacity Super Cab
6
Seating capacity Crew Cab
6
Fuel capacity Regular Cab
29 gallon (142" WB)
Fuel capacity Super Cab
29 gallon (148" WB), 34 gallon (164" WB)
Fuel capacity Crew Cab
34 gallon (160" WB), 48 gallon (176" WB)
FRONT SUSPENSION
Mono beam (narrow front track) with coil springs, shock absorbers, stabilizer bar (F-250/F-350 4x4) Mono beam (wide front track) with coil springs, shock absorbers, stabilizer bar (F-450)
Max Front GAWR (4x2)
5,000 (F-350 SRW)
Max Front GAWR (4x4) One
5,600 (F-350 SRW)
Max Front GAWR (4x2) Two
5,300 (F-350 DRW)
Max Front GAWR (4x4) Three
5,600 (F-350 DRW)
Front Springs
Coil
Shock absorbers
Heavy-duty gas
REAR SUSPENSION Type
Solid axle
Max Rear GAWR
7,230 lbs (F-350 SRW 4x2)
Max Rear GAWR One
6,780 lbs (F-350 SRW 4x4)
Max Rear GAWR Two
10,300 lbs (F-350 DRW 4x2)
Max Rear GAWR Three
9,900 lbs (F-350 DRW 4x4)
Rear Springs
Leaf
Stabilizer bar
Standard on DRW pickup; optional in select packages on SRW pickup
STEERING Assist
Power Hydraulic
BRAKES Type
4-wheel vented-disc ABS (standard)
WHEELS Type
Steel or aluminum
Number of studs
10
Towing Conventional Towing Regular Cab F-250 4x2/4x4 (lbs)
24,800/24,800
Towing Conventional Towing SuperCab F-250 4x2/4x4 (lbs)
26,700/26,700
Towing Conventional Towing Crew Cab F-250 4x2/4x4 (lbs)
27,000/27,000
Towing 5th Wheel / Gooseneck Towing Regular Cab F-350 4x2/4x4 (lbs)
32,900/32,500
Towing 5th Wheel / Gooseneck Towing SuperCab F-350 4x2/4x4 (lbs)
32,500/32,100
Towing 7th Wheel / Gooseneck Towing Crew Cab F-350 4x2/4x4 (lbs)
32,300/31,800
Payload Regular Cab 141.6" WB Long 8ft lbs DRW 4x2/4x4
6,950/6,519
Payload SuperCab 164.2" WB Long 8ft lbs DRW 4x2/4x6
6,504/6,085
Payload Crew Cab 176" WB Long 8ft lbs DRW 4x2/4x8
6,316/5,824
Payload Regular Cab 141.6" WB Long 8ft lbs SRW 4x2/4x4
4,375/4,844
Payload SuperCab 148" WB Short 6.75ft lbs SRW 4x2/4x5
4,253/4,623
Payload SuperCab 164.2" WB Long 8ft lbs SRW 4x2/4x6
4,423/4,796
Payload Crew Cab 159.8" WB Short 6.75ft lbs SRW 4x2/4x7
4,175/4,439
Payload Crew Cab 176" WB Long 8ft lbs SRW 4x2/4x8
4,134/4,572
Transmission Type
TorqShift 10-speed SelectShift Automatic®
Case material
Aluminum
Power Takeoff
Live-drive access on driver side
Gear ratios 1st
4.696:1
Gear ratios 2nd
2.985:1
Gear ratios 3rd
2.146:1
Gear ratios 4th
1.769:1
Gear ratios 5th One
1.520:1
Gear ratios 6th Two
1.275:1
Gear ratios Reverse
-4.866:1
Gear ratios First
4.615:1
Gear ratios Second
2.919:1
Gear ratios Third
2.132:1
Gear ratios Fourth
1.773:1
Gear ratios Fifth
1.519:1
Gear ratios Sixth
1.277:1
Gear ratios Seventh
1.1
Gear ratios Eighth
0.851:1
Gear ratios Ninth
0.687:1
Gear ratios Tenth
0.632:1
Gear ratios Reverse One
-4.695:1
