2025 Ford 2024 Super Duty® F-450® Platinum 6.7L Power Stroke® V8 Turbo Diesel
Pickup TrucksSuper-Duty
Description
Ford- 2024 Super Duty® F-450® Platinum 6.7L Power Stroke® V8 Turbo Diesel
Specifications
Manufacturer
Ford
Model
2024 Super Duty® F-450® Platinum 6.7L Power Stroke® V8 Turbo Diesel
Year
2025
Category
Pickup Trucks
Subcategory
Super-Duty
Regular Cab Front (in) Head room
40.8
Regular Cab Front (in) Shoulder room
66.7
Regular Cab Front (in) Hip room
62.5
Regular Cab Front (in) Max leg room
43.9
Super Cab Front (in) Head room
40.8
Super Cab Front (in) Shoulder room
66.7
Super Cab Front (in) Hip room
62.5
Super Cab Front (in) Max leg room
43.9
Crew Cab Front (in) Head room
40.8
Crew Cab Front (in) Shoulder room
66.7
Crew Cab Front (in) Hip room
62.5
Crew Cab Front (in) Max leg room
43.9
Super Cab Rear (in) Head room
40.3
Super Cab Rear (in) Shoulder room
65.8
Super Cab Rear (in) Hip room
64.7
Super Cab Rear (in) Max leg room
33.5
Crew Cab Rear (in) Head room
40.4
Crew Cab Rear (in) Shoulder room
65.9
Crew Cab Rear (in) Hip room
64.7
Crew Cab Rear (in) Max leg room
43.6
Front (rotor diameter)
15.39" (391 mm)
Rear (rotor diameter)
15.75" (400 mm)
WHEELS size
19.5" DRW
Bolt-circle diameter
8.86" (225 mm) DRW
Engine Name
6.7L Power Stroke® V8 Turbo Diesel
Engine Configuration
90-degree diesel V8, single turbocharger, in-block cams and overhead valves
Fuel injection/delivery
High-Pressure Common-Rail
Engine control system
Electronic
Induction system
Variable Geometry Turbocharger; with charge air cooler
Battery
Dual 12V-volt 750CCA 78-AH
Standard Alternator
250-amp
Cooling system
Pressurized series flow
Oil Life Monitor
Intelligent Oil Life Monitor®
Cylinders
8
Cylinder head
Aluminum
Block material
Compacted graphite iron
Valve operation
Push rod/rocker arms
Camshaft drive
Gear
Bore
3.90"
Stroke
4.25"
Compression ratio
15.2:1
Horsepower/rpm
500 @ 2,600
Torque lb-ft/rpm
1,200 @ 1,600
Recommended fuel
Ultra-low sulfur diesel/B20
Seating capacity Regular Cab
3
Seating capacity Super Cab
6
Seating capacity Crew Cab
6
Fuel capacity Regular Cab
29 gallon (142" WB)
Fuel capacity Super Cab
29 gallon (148" WB), 34 gallon (164" WB)
Fuel capacity Crew Cab
34 gallon (160" WB), 48 gallon (176" WB)
FRONT SUSPENSION Type
Mono beam (narrow front track) with coil springs, shock absorbers, stabilizer bar (F-250/F-350 4x4) Mono beam (wide front track) with coil springs, shock absorbers, stabilizer bar (F-450)
Max Front GAWR lbs (4x2)
5,600 (F-450 4X2)
Max Front GAWR lbs (4x4) One
5,600 (F-450 4X4)
Front Springs
Coil
Shock absorbers
Heavy-duty gas
REAR SUSPENSION Type
Solid axle
Max Rear GAWR (F-450 DRW 4x2)
9,900 lbs
Max Rear GAWR (F-450 DRW 4x4) One
9,900 lbs
Rear Springs
Leaf
Stabilizer bar
Standard on DRW pickup; optional in select packages on SRW pickup
STEERING Assist
Power Hydraulic
BRAKES Types
4-wheel vented-disc ABS (standard)
WHEELS Type
Steel or aluminum
WHEELS Size
17," 18" or 20"
Number of studs
10
Towing Conventional Towing Regular Cab F-450 4x2/4x4 (lbs)
25,000/25,000
Towing Conventional Towing Crew Cab F-450 4x2/4x4 (lbs)
30,000/30,000
Towing 5th Wheel / Gooseneck Towing Regular Cab F-450 4x2/4x4 (lbs)
38,600/36,900
Towing 5th Wheel / Gooseneck Towing Crew Cab F-450 4x2/4x4 (lbs)
34,700/32,500
Payload Regular Cab 141.6" WB Long 8ft lbs DRW 4x2/4x4
6,297/5,898
Payload Crew Cab 176" WB Long 8ft lbs DRW 4x2/4x4
5,638/5,336
Case material
Aluminum
Power Takeoff
Live-drive access on driver side
Gear ratios 1st
4.696:1
Gear ratios 2nd
2.985:1
Gear ratios 3rd
2.146:1
Gear ratios 4th
1.769:1
Gear ratios 5th One
1.520:1
Gear ratios 6th Two
1.275:1
Gear ratios Reverse
-4.866:1
Transmission Type
TorqShift 10-speed SelectShift Automatic®
Gear ratios First
4.615:1
Gear ratios Second
2.919:1
Gear ratios Third
2.132:1
Gear ratios Fourth
1.773:1
Gear ratios Fifth
1.519:1
Gear ratios Sixth
1.277:1
Gear ratios Seventh
1.1
Gear ratios Eighth
0.851:1
