Description
Ford MAVERICK® LARIAT 2.0L EcoBoost
Specifications
Manufacturer
Ford
Model
MAVERICK® LARIAT 2.0L EcoBoost
Year
2025
Category
Pickup Trucks
Subcategory
Super Duty Pickups
Wheelbase
121.1
Length
199.7
Height - Maximum
68.7
Width - Maximum Body Width - Measured to Body Mirrors
83.5
Width - Mirrors Folded
77.9
Vehicle Track - Front
63.4
Vehicle Track - Rear
62.8
Overhang - Front
34.1
Overhang - Rear
44.5
Front of Bumper to Back of Cab
137.6
Approach Angle (degrees) - FWD/AWD
20.6/21.6
Approach Angle (degrees) - FX4/Tremor
21.6/30.7
Departure Angle (degrees) - FWD/AWD
21.9/21.2
Departure Angle (degrees) - FX4/Tremor
21.2/22.2
Ramp Breakover Angle (degrees) - FWD/AWD
16.6/18.1
Ramp Breakover Angle (degrees) - FX4/Tremor
18.1/19.9
Ground Clearance (Minimum) (in) - FWD/AWD
8.3/8.6
Ground Clearance (Minimum) - FX4/Tremor
8.6/9.4
Curb Weight(lbs) - 2.0L EcoBoost - FWD/AWD
3,563/3,731
Lift-in Height
30.1
Pickup Body Height
20.3
Pickup Body Length at Floor
54.4
Cargo Width - Wheel House
42.6
Exposed Cargo Width
53.3
Cargo Volume (cu ft)
33.3
Head Room - Front
40.3
Head Room - Front (with moonroof)
38.0
Head Room - Second
39.6
Head Room - Second (with moonroof)
39.5
Leg Room - Front
42.8
Hip Room - Front
55.4
Hip Room - Second
54.1
Shoulder Room - Front
57.3
Shoulder Room - Second
55.6
Passenger Volume (cu ft)
100.3
Body Type
Unibody, SuperCrew (4-Door), Compact Pickup
Max Seating
5
Maximum Towing
4,000 lbs With Max Tow Package (4K Tow Pack)
Fuel Capacity
16.5 Gallons on 2.0L Gas EcoBoost
Drive Type
AWD (2.0L EcoBoost Only)
Available Engines
2.0L EcoBoost (Gas engine)
2.0L Horsepower | Torque
HP = 250 @ 5,500 rpm | TQ = 277 lb-ft @ 3,000 rpm
Transmission
8-Speed Automatic (2.0L EcoBoost)
Cargo Box
Imperial (inches unless otherwise noted)
Leg Room - Second
35.9 (2.5L Hybrid) / 36.9 (2.0L)
Engine
2.0L EcoBoost (Available)
Configuration
Aluminum block and head, I-4
Manufacturing Location
Cleveland, Ohio and Valencia, Spain
Intake Manifold
Composite
Exhaust Manifold
Integrated
Valvetrain
DOHC, Ti-VCT
Pistons
Aluminum
Connecting Rods
Powder Forged
Bore and Stroke
3.44 x 3.27 in
Displacement
122 cu in
Compression Ratio
9.3:1
Crankshaft
Forged Steel
Horsepower*
250 hp @ 5,500 rpm
Torque*
277 lb-ft @ 3,000 rpm
Fuel Delivery
GTDI
Oil Capacity
5.5 Quarts
Coolant Capacity
9.2 Quarts
Electric Motor Type
Permanent Magnet Electric Traction (Ford In House E_Motor)
Electric Motor Output
94 kW/173 lb-ft battery peak
Battery Cooling System
Liquid
Battery Location
Passenger Side Under Cabin
Gear Ratios
1st: 4.69
Gear Ratios One
2nd: 3.31
Gear Ratios Two
3rd: 3.01
Gear Ratios Three
4th: 1.92
Gear Ratios Four
5th: 1.45
Gear Ratios Five
6th: 1
Gear Ratios Six
7th: 0.75
Gear Ratios Sven
8th: 0.62
Final Gear Ratio
3.63 Standard/3.81 with 4K Trailer Tow Package/3.81 with Tremor® Off-Road Package
Reverse
-2.96
Steering
Electric power-assisted steering (EPAS)
Turning Circle (Curb to Curb)
40 Feet
Front Suspension
Independent MacPherson strut-type suspension with coil springs, twin-tube hydraulic gas-pressurized shocks, stabilizer bars, aluminum lower control arm, steel sub-frame and cast knuckle
Rear FWD Suspension
Independent twist-beam rear suspension with integrated stabilizer bar, Ford patented “force vectoring springs”, twin-tube hydraulic gas-pressurized dampers
Rear AWD Suspension
Independent multi-link trailing arm suspension with twin-tube hydraulic gas-pressurized dampers, coil springs, stabilizer bar, steel sub-frame and cast knuckle
Rear AWD with FX4 Package Suspension
Independent multi-link trailing arm suspension with mono-tube hydraulic gas-pressurized dampers with hydraulic rebound stop, coil springs, stabilizer bar, steel sub-frame and cast knuckle
Brakes
4-wheel disc brakes with ABS and regenerative braking system
Towing Engine
2.0L EcoBoost
Towing Base (FWD/AWD)
2,000 lbs / 2,000 lbs
Towing 4K Tow Package (AWD)
4,000 lbs
