Description
Ford Expedition® XL STX(4x2/4x4 Expedition MAX)
Specifications
Manufacturer
Ford
Model
2024 Expedition® XL STX(4x2/4x4 Expedition MAX )
Year
2025
Category
Automobiles
Subcategory
Automobiles
Wheelbase
131.6
Length
221.9
Height
76.4/76.2
Width - Excluding Mirrors
79.9
Width - Including Mirrors
93.4
Width - with Mirrors Folded
83.6
Front Track
67.6
Rear Track
67.2
Front Overhang
38.2
Rear Overhang
52.0
Approach Angle (degrees)
24.0/23.7
Departure Angle (degrees)
21.5/21.3
Ramp Breakover Angle (degrees)
20.3/20.1
Minimum Running Ground Clearance
9.8/9.7
Head Room - 1st Row
42.0
Head Room - 2nd Row
40.0
Head Room - 3rd Row
37.4
Max Leg Room - 1st Row
43.9
Leg Room - 2nd Row
41.5
Leg Room - Second Row (Seat Full Rearward) [in]
42.6
Leg Room - 3rd Row
36.1
Leg Room - Third Row (Second Row Seat Full Forward) [in]
40.9
Hip Room - 1st Row
62.2
Hip Room - 2nd Row
62.6
Hip Room - 3rd Row
51.4
Shoulder Room - 1st Row
64.9
Shoulder Room - 2nd Row
64.8
Shoulder Room - 3rd Row
64.3
Passenger Volume
172.0
Cargo Volume Behind First Row
121.5
Cargo Volume Behind Second Row
73.3
Cargo Volume Behind Second Row - Second Row Seat Full Forward [cu ft]
79.6
Cargo Volume Behind Third Row
34.3
Cargo Volume Behind Third Row - Third Row Seat Full Upright [cu ft]
36
Fuel Capacity
27.8
Drive type
Rear-wheel drive (std.)
Engine type
3.5L EcoBoost® V6
Transmission
10-Speed automatic with SelectShift®
Final drive ratio
3.31 Non-Limited Slip
Recommended fuel
Regular Unleaded
EPA-Estimated Rating (Expedition MAX 4x2)
16 city / 23 hwy / 19 combined mpg
EPA-Estimated Rating (Expedition MAX 4x4) one
16 city / 21 hwy / 18 combined mpg
Horsepower (SAE net@rpm)
380 @ 5,000 (XL-STX, XLT). 400 @ 5,000* (Limited , King Ranch, Platinum)
Torque (lb-ft@rpm)
470 @ 2,250 (XL-STX, XLT) 480 @ 2,250* (Limited, King Ranch, Platinum)
H.O. Tune Horsepower (SAE net@rpm)
440 @ 5,000 *
H.O. Tune Torque (lb-ft@rpm)
510 @ 2,250
Compression ratio
10.5:1
Valvetrain
Twin independent Variable Camshaft Timing (Ti-VCT)
Fuel delivery
Gasoline Direct Injection
Exhaust
Single, stainless steel (Dual, stainless steel on Limited Stealth Performance and Timberline)
Engine block type
Die-cast aluminum
Cylinder head material
Aluminum alloy
Maximum Towing Capacity Expedition MAX 4x2
9,000 lbs
Maximum Towing Capacity Expedition MAX 4x4 one
9,000 lbs
Maximum Loaded Trailer Weight (Lbs) 4x2
6,300
Maximum Loaded Trailer Weight (lbs) 4x4 one
6000
Axle Ratio
3.73
GCWR (4x2/4x4) (Lbs)
12,500 / 12,400
Base Curb Weight
5368/5623
Maximum Seating Capacity
8
Drivetrain
Rear wheel drive (standard)
